Function
It is suitable for compressing and packing loose materials such as waste paper/box, waste plastic film/bottle, cotton yarn, waste cotton, cloth, sack, hair ball, straw and so on.
Features
1. The packages are manually bundled, with consistent specifications and high density, suitable for warehousing and logistics transportation.
2. The use of upper type cylinder, hydraulic drive; Packing pressure from 3 tons to 315 tons, complete specifications.
Technical Specification
|
Paper /Plastic Baler
|
Main Cyl.Force
(ton)
|
Press Box Size
(L×W×H/mm)
|
Bale Size
(W×H/mm)
|
Bale Weight-carton
(kg)
|
Power
(kw)
|
|
Y82T-25
|
25
|
1100×800×1650
|
1100×800
|
120-180
|
15
|
|
Y82T-35
|
35
|
1100×800×1500
|
1100×800
|
200-250
|
15
|
|
Y82T-63
|
63
|
1100×900×1500
|
1000×900
|
200-300
|
15
|
|
Y82T-63B
|
63
|
1100×1100×1600
|
1100×1100
|
300-350
|
15
|
|
Y82T-100B
|
100
|
1100×1100×1600
|
1100×1100
|
350-400
|
18.5
|
Technical Specification
|
Wool Tops Baler
|
Main Cyl.Force
(ton)
|
Press Box Size
(L×W×H/mm)
|
Bale Size
(W×H/mm)
|
Bale Weight-carton(kg)
|
Power
(kw)
|
|
Y82-120Q
|
120
|
1120×780×2250
|
1120×780
|
24/36
|
22
|
|
Y82-200Q
|
200
|
1100×780×2250
|
1100×780
|
36/42
|
45
|
|
Y82-315Q
|
315
|
1090×780×2700
|
1090×780
|
36/42
|
40
|
Technical Specification
|
The Piece Goods Packing Machine
|
Main Cyl.Force
(ton)
|
Table Size
(W×H/mm)
|
Ram Size
(W×H/mm)
|
Space between ran&bottom
|
Power
(kw)
|
|
Max(mm)
|
Min (mm)
|
|
Y82-25B
|
25
|
1200×750
|
1100×680
|
1250
|
350
|
15
|
|
Y82-160B
|
160
|
1215×500
|
1215×500
|
1000
|
200
|
22
|
Technical Specification
|
Coke bottle baler
|
Main Cyl.Force
(ton)
|
Press box size
(L×W×H/mm)
|
Bale size
(W×H/mm)
|
Bale weight-waste carton
(kg)
|
Power
(kw)
|
|
Y82-30F
|
30
|
1100×550×2000
|
1100×550
|
100
|
11
|
Technical Specification
Yarn & Waste
carton baler
|
Main Cyl.Force
(ton)
|
Press box size
(L×W×H/mm)
|
Bale size
(W×H/mm)
|
Bale weight-waste carton
(kg)
|
Power(kw)
|
|
Y82-25M
|
25
|
980×430×1500
|
980×430
|
70
|
15
|
